Truck Scales

Starting at $1,250.00

Buy Now

    Truck scales are often integral components of a company's throughput and profit stream. Operations that weigh 10 trucks per day, and those that weigh hundreds, both need the most accurate and reliable truck scale systems to ensure that their business is both efficient and profitable.

    Walz Scale custom-integrated truck scales and weighbridge scale systems offer rugged designs, high performance interface options, and the most advanced technology on the market. Walz Scale truck scales for sale are available in numerous configurations to match the needs of any application, from light farm use to extreme heavy capacity applications.

    Farmers are encouraged to check-out the various truck scales at AgWeigh.com as well. From portable truck scales to grain dump truck scales, Walz Scale is an industry leader for a wide range of advanced weighing solutions.

    Features of Truck Weigh Scales by Walz Scale

    • Heavy Duty Truck Scale Design
    • Steel and Concrete Deck Truck Scales
    • Top Access to All Load Cells
    • Highest Quality Truck Scale Finish
    • Heavy Capacity Load Cells
    • NTEP Certified Truck Scales for Sale
    • High CLC Rating Among Truck Weigh Scales
    • Multiple Truck Scale Sizes/Capacities Available
    • Truck Scales are Field Serviceable
    • Local Support on Truck Scale Sales
    • Truck Scale Rental Solutions



    Choose Your Base Model SAVE 5% WHEN YOU PAY WITH CASH!

    AXW-20-TS Truck Scale

    Specs:

    • 40,000 Lb axle capacity truck scale
    • Pad dimensions: 27.5" X 17"
    • Aluminum construction
    • Built-in weight display
    • Battery operation
    • Pre-calibrated & ready to weigh
    • Price per pad

    Base Price

    $1,250.00

    Configure This Model >

    AXW-30-TS Truck Scale

    Specs:

    • 60,000 Lb axle capacity truck scale
    • Pad dimensions: 31.5" X 17"
    • Aluminum construction
    • Portable transport cases included
    • Water protected design
    • Pre-calibrated & ready to weigh
    • Qty (2) pads (sold in pairs)

    Base Price

    $3,900.00

    Configure This Model >

    AXW-45-TS Truck Scale

    Specs:

    • 100,000 Lb axle capacity truck scale
    • Pad dimensions: 31.5" X 27.5"
    • Aluminum construction
    • Portable transport crate included
    • Spare cabling included
    • Water protected design
    • Qty (2) pads (sold in pairs)
    • Weighing terminal included

    Base Price

    $11,200.00

    Configure This Model >

    AXHD-7-TS Truck Scale

    Specs:

    • 7' Long platforms truck scale
    • 60,000 lb axle capacity
    • Qty (2) platforms per set
    • Heavy duty steel construction
    • Removable ramps
    • Yellow safety stripe
    • Heavy duty load cell design
    • Lifting eyes for easy transport
    • Pre-calibrated and ready to weigh

    Base Price

    $6,000.00

    Configure This Model >

    AXHD-11-TS Truck Scale

    Specs:

    • 11' Long platform truck scale
    • 60,000 lb axle capacity
    • Qty (2) platforms per set
    • Heavy duty steel construction
    • Removable ramps
    • Yellow safety stripe
    • Heavy duty load cell design
    • Lifting eyes for easy transport
    • Pre-calibrated and ready to weigh

    Base Price

    $7,000.00

    Configure This Model >

    AG-I-1229 / AG-I-1229 Dump Pit Truck Scale

    Specs:

    • Dual scale system for incorporation with a dump pit
    • Scale one dimensions: 12' wide x 29' long
    • Scale two dimensions: 12' wide x 29' long
    • NTEP Certified "Legal-For-Trade"
    • Steel deck design
    • Diamond safety tread plate
    • Structural beam construction
    • Top access design
    • Galvanized suspension components
    • Tension suspension system
    • Modular design
    • Simple installation

    Base Price

    $31,500.00

    Configure This Model >

    AG-I-1229 / AG-I-1243 Dump Pit Truck Scale

    Specs:

    • Dual scale system for incorporation with a dump pit
    • Scale one dimensions: 12' wide x 29' long
    • Scale two dimensions: 12' wide x 43' long
    • NTEP Certified "Legal-For-Trade"
    • Steel deck design
    • Diamond safety tread plate
    • Structural beam construction
    • Top access design
    • Galvanized suspension components
    • Tension suspension system
    • Modular design
    • Simple installation

    Base Price

    $34,650.00

    Configure This Model >

    AG-I-1272 Truck Scale

    Specs:

    • Dimensions: 12' wide X 72' long truck scale
    • NTEP Certified "Legal-For-Trade"
    • Steel deck design
    • Diamond safety tread plate
    • Structural beam construction
    • Top access design
    • Galvanized suspension components
    • Tension suspension system
    • Modular design
    • Simple installation

    Base Price

    $32,000.00

    Configure This Model >
    Learn More About This Product

    Truck Scales

    Image of Roll Off Scale System

    Features of Truck Scales by Walz Scale

    • Heavy Duty Truck Scale Design
    • Aluminum, Steel and Concrete Deck Truck Scales
    • Top Access to All Load Cells
    • Highest Quality Truck Scale Finish
    • Heavy Capacity Load Cells
    • NTEP Certified Truck Scales for Sale
    • High CLC Rating Among Truck Weigh Scales
    • Multiple Truck Scale Sizes/Capacities Available
    • Truck Scales are Field Serviceable
    • Local Support on Truck Scale Sales
    • Truck Scale Rental Solutions



    In motion Axle Scale

    AXW Model Truck Scale

    Looking for a truck scale that you can move by hand?  If so our AXW portable axle scales are the perfect choice.  These truck scales are made of high strength aluminum allowing for operators to move then by hand.  These are the same type of truck scale that are used by police to monitor vehicle loads on the highway.  We put our 50 years of experience into developing these truck scales to meet the demanding applications of our customers.

    Capacities: Up to 100,000 Lbs per axle (dependent on model chosen)

    Resolution: 50 lbs

    Accuracy: +_1%

    AXW Brochure and Specifications





    Rent Portable Truck Scales from Payload Pros


    Truck Scale

    AXW 20

    The AXW-20 series truck scale is designed for applications that require a portability and basic weighing.  The AXW-20 truck scale is designed to provide high accuracy axle weights with extreme portability at an economical price.  If your looking for a basic truck scale, this is the one for you.

    Capacity: 40,000 Lbs per axle

    Resolution: 50 lbs

    Accuracy: +_1%

    Features

    Light weight aluminum construction - Integrated lifting handle - Battery operation - LCD display - Rated for outdoor use - No cables required




    Rent Portable Truck Scales from Payload Pros


    Truck Scale

    AXW 30

    The AXW-30 series is designed for applications that require truck weighing portability with more advanced weighing functions.  The AXW-30 truck scales incorporate aluminum construction along with portable ramps and an advanced weighing terminal.  These truck scales are capable of weighing trucks in either static or dynamic operation.

    Capacity: 60,000 Lbs per axle

    Resolution: 50 lbs

    Static Accuracy: +_1%

    In-motion Accuracy: +_3.5%

    Features

    Light weight aluminum construction - Integrated lifting handle - Removable Ramps - Rechargeable Battery operation - Touch screen display - Integrated printer - PC computer interface - USB interface - Static weighing mode - In-motion weighing mode




    Rent Portable Truck Scales from Payload Pros


    Truck Scale

    AXW 45

    The AXW-45 series is designed for applications that require heavy duty truck weighing.  The AXW-45 portable axle scales are designed for weighing heavy axle loads in remote locations.  The portable scale base provided allows for weighing on compact earth without the need for a concrete or asphalt base.

    Capacity: 90,000 Lbs per axle

    Resolution: 100 lbs

    Static Accuracy: +_1%

    In-motion Accuracy: +_3.5%

    Features

    Aluminum construction - Portable base - Removable ramps - Rechargeable Battery operation - Touch screen display - Rated for outdoor use - Integrated printer - PC computer interface - USB interface - Static weighing mode - In-motion weighing mode



    AXHD Heavy Duty Axle Scale Construction

    Truck Scale

    AXHD Model

    The AXHD truck scales are designed for the weighing of vehicles by axle group.  The systems work by weighing each axle group at a time and then adding all the axle group weights to provide the total weight of the vehicle.  These truck scales are available in multiple lengths to match the axle groups of your trucks.  Out 7 ft long version is ideal for trucks with tandem axles, while our 11 ft version is used for trucks with split or triple axle groups.  This allows for easier weighing and faster throughput.

    Capacity: 60,000 lbs per axle group

    Resolution: 20 lbs

    Accuracy: +_ 0.5 - 1%



    Portable Axle Scale Steel Design

    Portable Truck Scale Features

    The AXHD truck scale systems were designed by our in-house engineers to be the best portable truck scale on the market. Below are a few of the features that we engineered into our truck scale.

    Removable ramps - Super heavy duty load cells - Only 2 load cells per scale pad - Top access for service - Superior strength steel design

    Lifting eyes for easy transport - Operates on earth or gravel ground (no need for concrete) - Yellow safety paint strip for drivers - Software interface



    Removable Portable Axle Scale Ramps

    Easy Transportation

    The AXHD truck scales are designed for simple easy transport. this allows for simple operation at multiple locations as well as results in lower freight transport costs. If your looking for a portable truck scale that will provide many years of service, the AXHD models are the one for you.

    Each system ships with the following components:

    Qty (2) AXHD scale pads

    Qty (4) Removable ramps

    Qty (1) Weighing terminal

    Pre-Calibrated and ready to weigh



    Portable Axle Scale Weighing Terminal

    Weight Terminal

    The portable weight terminal is designed to provide portable operation of your truck scale.  The built in rechargeable battery provides hours of scale operation, while the integral printer allows for the printing of axle and total vehicle weights.  The backlight LCD touch display is extremely easy to see and provides operators with a very simple interface for operating the scale system.

    Portable Axle Scale Weighing Terminal Features

    Rechargeable battery or 115VAC operation - Touch screen display - Built-in printer - Connection to multiple scales - USB output - PC software interface



    Portable Axle Scale Weighing Terminal

    Complete Inventory of Certified Truck Scales for Sale

    Walz Scale truck scales and weighbridge scale systems offer rugged designs, high performance interface options, and the most advanced technology on the market. Walz Scale truck scales for sale are available in numerous configurations to match the needs of any application, from light farm use to extreme heavy capacity applications.

    Farmers are encouraged to check-out the various truck scales at AgWeigh.com. From portable truck scales to grain dump truck scales, Walz Scale is an industry leader for a wide range of advanced weighing solutions.



    Our standard duty truck scales are the ideal solution for applications that require high accuracy certified weighing.  All of our Standard Duty Truck Scales are NTEP Certified and approved by the federal govement to meet all the accuracy requirements.

    Image of Roll Off Scale System

    Advanced Weighing Features

    All of our standard duty scales are designed for durability and high accuracy.  The design of our truck scales are the result of nearly 50 years of service to the truck weighing market.  What we leaed from our customers drove our decision making process.

    Image of Roll Off Scale System

    12' Wide Truck Scales at 10' Wide Prices

    The standard 12' wide truck scale deck is ideal for allowing drivers to access the farm scale safely.  The 12 feet wide deck on these standard duty truck scales is our standard design, however we offer truck scales in 10', 11', 12', & 14' wide.

    Image of Roll Off Scale System

    Galvanized Scale Components

    The galvanized suspension components on our truck scale systems are designed to increase component life and reduce service issues. Look closely at what others are offering, no other truck scale is built with standard galvanized components.  ll of the load cell cabling is protected with a metal cover and is run through conduit within the scale, to eliminate damage from rodents and the environment.

    Image of Roll Off Scale System

    Steel Deck Scales

    Our steel deck scales are designed with either U-beam or I-beam structural steel supports running longitudinally along the length of the scale.  This ensures that the truck is fully supported at any location on the scale's deck.  Each of our scales also arrives with a yellow safety stripe located on the edges of the scale decks.  This provides drivers with a visual representation of the scales edges.  Guide rails are also available as an option on all of our truck scales.

    Image of Roll Off Scale System

    Modular Design Truck Scales

    The modular design of our truck scales allows customers to install the scales onsite without the need for a crane. Installing our standard duty truck scales is simple and easy, all you need onsite are some bottle jacks, cribbing, and a lift truck with forks.  Customers can now install their own truck scale, saving $$$$ on the installation.

    Farm Truck Scales for Loading Out

    Top Access Cover Plates

    All of the electronics and load cells are accessible from the top of the scale, by removing the steel access plates.  This reduces overall costs for any repairs or maintenance that are required on the scales.



    Legal-For-Trade Farm Scales

    Legal-For-Trade Truck Scales

    All of our truck scale systems are NTEP certified "Legal-For-Trade" across the United States.  NTEP approval is only granted to those truck scale systems that deliver and maintain the highest accuracy.

    Manage Harvest Production

    Grain Dump Integration

    For our customers in the grain industry, we have developed a cost effective solution for incorporating our truck scales into their grain dump site.  This greatly improves vehicle throughput during harvest.

    Easy-to-Use Farm Truck Scales

    Simple Foundation Requirements

    All of our trucks scales have been designed to work in any foundation plan required for your area.  While most of our customers choose to poor a simple slab foundation, our truck scales can be installed on Pier and Pit Foundations as well.  Foundation prints are supplied with every truck scale purchase.

    Image of Roll Off Scale System

    Designed for Easy Installation

    We have designed our truck scales to be extremely easy to install.  In fact the installation process is so easy that many of our customers choose to perform their own installation.  Each scale purchased will ship with very simple installation instructions to walk you through the process.  And our technical staff is available 24-7 to help support and and answer any questions that you may have.

    Agriculture Management Software System

    Customer Testimony

    "The scale we purchased from Walz Scale has proved to be an essential, irreplaceable investment for our farm operation. In conjunction with their scale software, Yield Pro, Walz Scale has allowed me to manage my grain inventory with a level of accuracy and confidence required to maximize our profits.

    Working with Walz Scale, we were able to customize the Yield Pro software to meet our farm's specific needs. With its built in shrink calculation, individual bin level tracker, and custom export reports, we now have the precise control over our grain inventory we never had before.

    The remote weight display, weight capture indicator, and RFID tags on my trucks makes weighing in and out much more efficient by eliminating the need to continuously get in and out of the truck to punch your ticket.

    With the entire installation taking just a weekend, our new scale system from Walz Scale was operational and ready to help us begin maximizing our profit.

    With all these great features, excellent customer support, and most importantly, a very reasonable price tag, I would recommend this solution from Walz Scale to anyone looking to manage and track their operation more efficiently and confidently."

    Pope Farms, WI
